Chonky Palmtop.

Chonky Palmtop.

Chonky Palmtop.

Materials List:

• Printed parts - See the “Stl Files” derectory.
• Pi 4 (4gb minimum)
• Ampripper 3k PSU/Charger: https://www.tindie.com/products/kickstart_design/ampripper-3000-5v-3a-lipo-battery-charger/
• Chonker spim08hp cells:https://batteryhookup.com/products/2x-spim08hp-3-7v-8ah-cells-with-threaded-insert
• 7” Touchscreen: https://www.amazon.com/gp/product/B07L6WT77H/
• USB Hub: https://www.amazon.com/gp/product/B00L2442H0/
• Hinges: https://www.amazon.com/gp/product/B07GX8LQCX/
• Bolt and Nut Kit: https://www.amazon.com/gp/product/B093FWLJZC/
• 1/4” Screws: https://www.amazon.com/gp/product/B00GDYNHL6/
• 3/8” Screws: https://www.amazon.com/gp/product/B00GDYNJNM/
• Crkbt Classic PCB: https://www.littlekeyboards.com/collections/corne-pcb-kits/products/crkbd-classic-essentials-kit
• Your choice of choc switches.
• Diodes
• mcu, e.g. pro micro or elite c
• Machine Pin Sockets for mcu: https://www.adafruit.com/product/3647, https://www.adafruit.com/product/3646
• Keycaps: https://www.littlekeyboards.com/collections/keycaps/products/mbk-choc-low-profile-keycaps
• 22 Gauge Silicon Wire: https://www.amazon.com/gp/product/B07T4SYVYG/
• 18 Gauge Silicon Wire: https://www.amazon.com/gp/product/B073RDBW7L/
• In-line Fuses: https://www.amazon.com/gp/product/B07ZTYN9DY/ (higher amperage would be better maybe)
• XT60 Connector: https://www.amazon.com/gp/product/B01ETROGP4/
• Voltage Indicator: https://www.amazon.com/gp/product/B00YALUXH0/
• 6mm Tactile Buttons: https://www.adafruit.com/product/367
• 6mm Clear Top Buttons: https://www.adafruit.com/product/4183
• switch: https://www.amazon.com/gp/product/B008CZIG3I/
